Snow Line 560, 620, 620E
caution when turning on sloped surfaces.
„ Use the skid plates to adjust the distance of the
clearing plate from the surface. Do not operate
the machine on gravel surfaces.
„ Never lift or carry the machine while the engine is
running.
„ Do not eat, drink or smoke while filling with petrol
or engine oil.
„ Do not inhale petrol fumes.
„ Take precautions to ensure that discharged snow
does not cause injury to persons or animals or
damage to buildings, vehicles or other objects.
Make sure that traffic is not impaired and that driv-
ers are not endangered.
„ Keep hands out of the snow discharge chute while
the machine is running.
„ Keep hands and feet away from the auger and im-
peller while the machine is running.
„ Do not clear snow from roofs.
Assembly
Caution!
Do not operate the machine until it has been fully
assembled.
Required tools
„ 2 Open-end or ring spanners, size 10
„ Open-end or ring spanner, size 13
„ Hex key, 5 mm
„ Combination or needle nose pliers
„ Screwdriver
„ Spray oil
„ Tyre pump with pressure gauge (auto tyre valve)
Assembly sequence
Attaching the guide handle
1. Remove fastening screws from the snow blower
1-1).
(
2. Place the guide handle (
and insert the upper mounting screw with retaining
469 186_b
2) on the snow blower
plate on both sides (
screws yet.
3. Align the guide handle and screw in the lower
mounting screw on both sides (
4. Tighten all four mounting screws.
x The guide handle is attached.
Attaching and adjusting control cables
The same procedure applies for the wheel drive
and auger control cables.
1. Guide the control cable upward:
Guide the auger control cable through the
„
opening on the drive speed selection plate
3-1).
(
Guide the wheel drive control cable upward
„
under the drive speed selection plate (
2. Loosen the screw with the hook from the adjust-
ment nut (
4-1). The lock nut remains on the
screw.
3. Raise the clutch lever (
4. Mount the hook into the hole on the clutch lever
from the guide handle side (
5. Screw the adjustment nut to the attached screw
until there is no slack in the cable (lightly tightened)
7-1). Hold the cable while tightening so that it
(
does not twist.
6. Tighten the lock nut (
x The control cables are installed.
Attaching the drive speed selection lever
1. Guide the pre-assembled drive speed selection
lever through the drive speed selection plate
(
8-1).
2. Remove the mounting screw from the connection
bolt and attach the drive speed selection lever
9).
(
3. Secure the drive speed selection lever with the
horizontal mounting screw (
the screw yet.
4. Adjust the lever position with the adjustment screw
so that it engages into the slot for the first speed
8-2).
setting (1) (
GB
2-1). Do not tighten the
2-1).
3-2).
5).
6).
7-2).
10-1). Do not tighten
25
