5.2.1
Mounting the radiator thermostat
In case of visible damage of the existing radiator,
valve or heating pipes, please contact a specialist.
Remove the old thermostat dial from your radiator valve.
To do this, please proceed as follows:
•
Rotate the thermostat dial to the maximum value
(G) anti-clockwise (see figure 5). The thermostat
dial then no longer presses against the valve spig-
ot, making it easier to remove.
There are different ways of fixing the position of the ther-
mostat dial:
•
Union nut: Unscrew the union nut in an anti-
clockwise direction (F). The thermostat head can
then be removed (H).
•
Snap-on fastenings: Thermostat dials that are
fastened this way can be detached by turning the
fastener/union nut a little bit counter-clockwise
(F). The thermostat head can then be removed
(H).
•
Compression fitting: The thermostat dial is held
in place by a mounting ring which is held togeth-
er with a screw. Loosen this screw and remove
the thermostat head from the valve (H).
•
Threaded connection with set screw: Loosen the
set screw and remove the thermostat head (H).
Start-up
43
