RC48N
Zubehör (Maße)
Alle Maße in mm (bzw. inch)
Ankoppelgerät CD1000
ø = 4,5 (0.18")
i
ø = 10,0 (0.39")
a
t = 3,2 (0.13")
i = innen (internal)
a = außen (external)
t = Tiefe (depth)
Ankoppelgerät CD5000
Differenzstromwandler
Verwenden Sie nur Bender Differenzstromwandler für
RC48N.
10 RC48N_D00426_01_M_DEEN / 03.2024
Accessories (dimensions)
All dimensions in millimetres (inches)
Coupling device CD1000
40 (1.57)
Coupling device CD5000
380 (14.96)
351 (13.82)
Residual current transformers
Only Bender residual current transformers are to be
used for RC48N.
41,5 (1.63)
22 (0.86) 10,5 (0.41)
100 (3.94)
8x21 (0.31x0.83)
19 (0.75)
