118 Anhang B
Pin-Belegung: Mikrofon und
Kopfhörer/Lautsprecher
Tabelle B-8 Pin-Belegung: Mikrofon
Mikrofon
Mono-Line-Mikrofon
Tabelle B-9 Pin-Belegung: Mikrofon
Mikrofonbuchse
Anschluß
3,5-mm-Stereobuchse
(Monosignal auf Spitze und Ringmantel)
Stromversorgung
+5 Phantom auf Spitze
Typ
Unidirektionales Electret-Kondensatormikrofon
Tabelle B-10 Pin-Belegung: Kopfhörer
Spitze
Ring
Mantel
Links
Rechts Erde
Tabelle B-11 Technische Daten: Kopfhörer
Kopfhörer
Empfohlene Impedanz
Anschlüsse
Spitze
Ringmantel
Signal (+)
Erde offen (-)
35 ohm
3,5 mm stereo
