Push the battery pack
♦
Switch off the charger for at least 15 minutes
between successive charging sessions . Also
disconnect the power plug from the mains
power socket .
Attaching/disconnecting the battery
pack to/from the appliance
Inserting the battery pack:
♦
Push the rotation direction switch
the middle position (lock) . Allow the battery
pack
to click into the handle .
Removing the battery pack:
♦
Press the release button
battery pack .
Checking the battery charge level
♦
Press the battery charge level button
check the status of the battery (see also main
diagram) .
The status/remaining charge will be shown on
the battery display LED
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Fitting the additional handle
♦
Screw the additional handle
right of the appliance depending on how you work .
Changing tools
Your cordless screwdriver has a fully automatic
spindle lock
.
When the motor is stopped, the power train locks
so that the chuck
can be opened by turning
it
. Once you have attached the desired tool
and tightened it by turning the chuck
continue working . The spindle lock is automatically
released when the motor starts (ON/OFF
switch
pressed) .
Torque preselection/selecting the
operating mode
You can adjust the torque on the torque prese-
lector
and select between the drill setting
and the hammer drill setting
♦
Select a low level for small screws or soft
materials .
PSBSA 20-Li D4
back into the appliance .
into
and remove the
to
as follows:
onto the left or
, you can
.
♦
Select a high level for large screws, hard
materials or removing screws .
♦
Select the drill setting for drilling work by adjusting
the torque selection ring to the position .
♦
Select the hammer drill setting for hammer
drilling work by adjusting the torque selection
ring to the position
2-speed gearbox
CAUTION!
►
Operate the speed selection switch
when the appliance is at a standstill . Other-
wise the appliance can be damaged .
In first gear (speed selector switch
position: 1)
you can reach a speed of approx . 440 rpm and a
high torque . This setting is suitable for all screwing
work but also for the use of accessories .
In second gear (speed selector switch
position: 2)
you can reach a speed of approx . 1650 rpm for
carrying out drilling work .
Use
Switching on and off
Switching on:
♦
To start the appliance, press the ON/OFF
switch
and keep it pressed in .
The LED work light
switch
is depressed lightly or fully . This allows
for illumination of the work area in low lighting .
Switching off:
♦
Release the ON/OFF switch
appliance .
Adjusting the rotational speed
Press the ON/OFF switch
speed . Increasing the pressure increases the speed .
NOTE
►
The integrated motor brake ensures rapid
stoppage .
.
only
in
in
lights up when the ON/OFF
to switch off the
lightly for a low
GB │ CY │
7
■
