Teileliste - CARDIOSTRONG CST-EX20 Montage- Und Bedienungsanleitung

9.3

Teileliste

Nr. Anz. Bezeichnung (ENG)
A 1 MAIN FRAME
A1 1 SENSOR WIRE 1500mm
A2 1 Motor
A2-1 2 Motor-Screw
A3 1 Tension Cable
A3-1 1 Spring
A4 1 DC Line 350mm
A5 1 SENSOR WIRE 350mm
A5-1 2 SENSOR SCREW
A6 1 FLYWHEEL
A7 1 AXLE
A8 1 BEARING 6000Z
A8-1 1 BEARING 6300Z
A9 1 BUSH M10x14x9T
A10 4 NUT M10
A11 2 FLANGE NUT M8
A12 1 MAGNETIC HOUSING
A13 1 BOLT M6x55L
A14 1 NUT M6
A15 1 WASHER M6x19x1.5T
A16 1 WASHER M6x14x1.2T
A17 1 Nylon NUT M6
A18 1 BOLT M8x45L
A19 1 WASHER M8
A20 1 Nylon NUT M8
A21 1 PRESSING TAGGER
A22 1 SPRING
A23 1 BOLT M8x20L
A24 1 WASHER M8x22x1T
A25 1 Nylon NUT M8
A26 1 PRESSING PULLY
44
Nr. Anz. Bezeichnung (ENG)
A27 1 Nylon NUT
A28 1 BELT
A29 1 DRIVING PULLY
A30 1 MAGNETIC
A31 1 CRANK AXLE
A32 4 BOLT M6x16L
A33 4 SPRING WASHER M6
A34 4 Nylon NUT M6
A35 2 BEARING 6004zz
A36 2 C-CLIP
A37 2 CRANK
A38 2 FLANGE NUT M10
A39 2 PLATE COVER
A39-1 6 SCREW
A39-2 6 WASHER
A40 2 PLASTIC COVER
A41 2 C-CLIP
A42 2 BEARING 2203zz
A43 2 BOLT M8
A44 2 END CAP
A45 1 LEFT CHAIN COVER
A46 1 RIGHT CHAIN COVER
B 1 CENTRAL SUPPORT TUBE
B1 1 SENSOR WIRE 900mm
B2 1 HAND PULSE WIRE 650mm
B3 2 END CAP
B4 1 END PLUG
C 1 REAR STABILIZER
C1 2 END CAP
D 1 FRONT STABILIZER
D1 2 END CAP
EX20
