Key to device
See figure
1
1.
ON/OFF switch
2.
Sound processor program toggle**
3.
Micro-USB charging socket
4.
Microphone
5.
Call answer/hang-up button
6.
Sound processor microphone mute button**
Volume control
7.
Mounting clip
8.
Bluetooth pairing button (under the cover)
9.
Sound processor pairing button (under the cover)
10.
Introduction
The Cochlear
Wireless Phone Clip will allow you to connect your wireless Cochlear
™
Processor to Bluetooth
-enabled mobile phones. This enables clear and trouble-free phone
®
connectivity, whether you are at home, in the office or on the move.
When used with a Cochlear
Baha
Sound Processor, the Phone Clip also doubles as a basic
™
®
remote control making it possible for you to adjust the volume of your sound processor and
toggle through programs when you are not talking on the phone**.
You can also chose to mute your sound processor microphone to shut out ambient sound
while you are talking on the phone or when using the Phone Clip as a remote control**.
Please read this manual carefully to fully benefit from the Phone Clip. Ask your hearing care
professional if you have any questions.
For further information you can also visit the www.cochlear.com web site.
For your safety, carefully read the chapter "Important Information".
Warranty
The warranty does not cover defects or damage arising from, associated with, or related to the
use of this product with any non-Cochlear processing unit and/or any non-Cochlear implant.
See "Cochlear Global Limited Warranty card" for more details.
Contacting customer service
We strive to provide the best possible products and services to our clients. Your views and
experiences with our products and services are important to us. If you have any comments
you would like to share, please contact us.
Key to symbols
The following symbols will be used throughout these documents.
"Consult instructions for use" or "Operating instructions"
"Caution" or "Caution, consult accompanying documents"
CE-mark
Serial Number
Refer to instructions/booklet
Wireless enabled
ACMA (Australian Communications and Media Authority) compliant
Please ask your hearing care professional concerning disposal of this
device.
Bluetooth compatible
Made for iPhone symbol
Works with Android
Intended use
The Phone Clip is intended to make phones calls easier for wireless Cochlear sound processor
users. The Phone Clip essentially transfers signals between a Bluetooth
wireless sound processor.
All manuals and user guides at all-guides.com
Getting Started
Charging the Battery
See figure
Before using your Phone Clip for the first time:
•
•
•
•
Sound
™
Turning your Phone Clip on and off
Turning your Phone Clip on or off:
•
•
If the battery level is low the LED will flash yellow every 2 seconds indicating that the unit
should be recharged.
Pairing to Cochlear Sound Processors
Pairing the Phone Clip
1. Turn off your Cochlear sound processor(s).
2. Turn on your Phone Clip.
3. Remove the silver cap from the Phone Clip.
4. Press the pairing button once using the tip of a pen or similar object.
5. While pairing mode is active, turn on your sound processor.
Successful pairing will be indicated by either an audible melody played in the sound processor,
or by a flashing light on the sound processor (depending on the type of sound processor).
Bluetooth
If your mobile phone is Bluetooth
communicate with the Phone Clip only after completing two simple procedures: pairing and
connecting.
The pairing procedure allows you to control which Bluetooth
each other. Pairing only needs to be done once for each device to be used with your phone clip.
You can pair up to 8 Bluetooth
connected/active at a time.
The pairing procedure is described in the following section. Once a mobile phone has been
paired with the Phone Clip, the connection procedure configures the device to output its
audio signal through the Bluetooth
following section.
Pairing with your mobile phone
The pairing procedure is controlled by your mobile phone. Different mobile phones have
their own menu structures. Refer to your phone's manual if you cannot complete the pairing
procedure with the generic steps described here.
1. Turn your Phone Clip on and remove the silver cap. Place your mobile phone next to the
Phone Clip, and make sure your phone is on.
2. Find the connectivity settings on your phone. Look for the "Bluetooth" feature in the main
3. On your mobile phone, ensure that Bluetooth is turned on.
4. With the tip of a pen or similar object, press the small blue Bluetooth pairing button on the
5. Search for Bluetooth devices on the mobile phone.
6. Your mobile phone should present a list of Bluetooth devices discovered. Select "Hearing
7. Your mobile phone may then ask you to enter a passcode. If so, enter "0000" (four zeros).
Your Phone Clip should now be paired to your mobile phone. Some mobile phones may ask
which Bluetooth service you wish to enable. Select "Headset".
Connecting
Once your mobile phone and Phone Clip are paired, the mobile phone may need to be
connected before it will actually send the appropriate audio signals.
phone and the
®
This function should also appear in your mobile phone's "Bluetooth" menu, usually under a list
of "Paired devices." In that list, highlight your Phone Clip and select "Connect."
When your Phone Clip and mobile phone are connected, you may see a headset symbol on
the phone's display.
The connection between the Phone Clip and the mobile phone will be maintained for as
long as both devices are turned on and remain within range of each other. If either device is
switched off or gets out of range, you may have to perform the connection procedure again.
Some phones allow for "Automatic reconnection." We recommend that you activate this
feature if it is available. Refer to your mobile phone's manual for instructions.
2
Charge the battery fully for at least 3 hours, even if battery indicators indicate it is fully
charged (see the section "Light indicators").
During the charging process, the LED indicator will glow red. When fully charged and still
connected to the charger, the LED will glow green with intermittent red flashes every 2
seconds.
Charging a flat battery takes around 3 hours. The charger can be connected overnight; the
battery cannot be overcharged.
For safety reasons, recharge the battery only with chargers supplied by Cochlear.
Caution: Do not charge the Phone Clip while it is being worn.
On: slide the switch to the on position; the LED indicator will flash green every 2.5 seconds.
Off: slide switch to the off position; the LED will stop flashing
LED will flash yellow every two seconds and the device will now be in pairing mode for 20
seconds.
Pairing
®
®
-enabled and supports the appropriate profiles, it can
®
devices with the Phone Clip, but only 2 such devices can be
connection. This procedure is also described in the
®
menu or one of the sub-menus, such as "Connectivity".
See figure
back of your Phone Clip once.
4
. The Phone Clip will now be in Bluetooth
pairing mode for two minutes.
Aid Phone" from this list.
See figure
.
5
See figure
3
. The
devices can communicate with
®
