Ugolini MT micro Gebrauchsanweisung Seite 16

MT micro
freezers. Such bases have a sugar content of 34
degrees Baumé corresponding to 64 degrees
Brix.
For soft drinks the bases are to be diluted with
more water, on a 1 plus 5/5.5 basis.
In any case follow the syrup manufacturer's
instructions for both Granita and soft drink
recipes.
If natural juices (e.g. lemon, orange) as well as
sugarless products (e.g. coffee) are used,
dissolve 150 - 200 grams of sugar per liter.
IMPORTANT
Operate the dispenser with food products
only.
IMPORTANT
However Granita mix may be done, its Brix
(sugar percent content) must be at least 13.
5
Set the control switches as shown in chapter
7.1 DESCRIPTION OF CONTROLS.
6
Always leave the dispenser on, as the
refrigeration stops automatically when Granita
reaches the proper thickness. The mixers will
continue to turn.
7. 1 DESCRIPTION OF CONTROLS
The dispenser is equipped with a power switch. In
addition each bowl is individually operated by a
mixer/refrigeration switch. In fact it is possible to
dispense both soft drinks and Granita.
When a bowl is in Soft Drink mode the beverage
temperature is controlled by the corresponding
thermostat.
When a bowl is in Granita mode the mix viscosity
is controlled by the corresponding adjustment
screw located in the rear wall of each container
(for temperature and viscosity setting make
reference to chapter 7.2 OPERATION HELPFUL
HINTS).
ETC VERSION
All the switches are located on the faucet side of
the dispenser.
Dispenser controls functions are as follows (see
All manuals and user guides at all-guides.com
16
figure 1).
figure 1
Power switch (A)
0 position : power is turned OFF to all
functions.
I position : power is turned ON to all
functions and mixer run too.
Mixer/Refrigeration switches ( C) and (D)
Switch C : if pressed it activates the function
'DRINK'. In this case the (E) led
lights up.
Switch D : if pressed it activates the function
'SLUSH'. In this case the (F) led
lights up.
Thermostat (B)
It displays the temperature of product inside the
bowl.
Temperature alarm : if the temperature on display
flashes, it means that product remained for a
certain period at a temperature higher than the
max. admitted conservation temperature , and
therefore it is necessary to check the product
conditions.
Press for three seconds the button (D) to reset
the display .
IMPORTANT
If the dispenser is switched on when bowls
contain products at a temperature higher
than conservation temperature, the display
will flash. To have a fixed display , it is
necessary to press for three seconds the
button (D).
