IMPAC pyrometer IP 140
Uncertainty:
(with ε=1, t
=1 s,
90
T =10 to 40°C)
amb.
Repeatability:
Ambient temperature:
Storage temperature:
Protection class:
Weight:
CE-label:
Sighting:
1.1

Dimensions

Pyrometer with
thru lens view finder:
Pyrometer with
laser targeting light:
2

Overview

1
2
3
1 Focusable optics (with label with optical data)
2 4 threads for fixing the pyrometer or
accessory parts
3 Mounting rail
4 Type label
5 LC display
6 Extendable back cover
6
up to 400°C: 2°C
above 400°C: 0.3% of measured value in °C + 1°C
(Note: the pyrometer must be operate at least 30 min before these values are valid)
0.1% of measured value in °C + 1°C
0 to 53°C
- 20 to 60°C
IP65 (DIN 40050)
approx. 550 g
According to EU directives about electromagnetic immunity
Laser targeting light (max. power level < 1 mW,
λ = 630-680 nm, CDRH class II)
or built-in optimized thru-lens view finder
4 5
(ε=1, t =1 s, T
90
7
8
9
10
11
6
7 Screws for rear cover (3 mm allen screws)
8 Laser targeting light on/off switch or parallax free
view finder, dependent on the instrument's type)
9 Operating status for targeting light / laser
(on instruments with laser targeting light)
10 Male socket for electrical connections
11 LC display, extended
12 Setting keys
=10 to 40°C)
amb.
All dimensions in mm
12
