General description
An illustration of the most
important functional compo-
nents can be found on the
fold-out page.
Extent of the delivery
Carefully unpack the appliance and check
that it is complete:
- Cordless Drill
- 7 metal drill bits
(2/3/4/5/6/7/8 mm)
- 7 wood drill bits
(3/4/5/6/7/8/10 mm)
- 25-part bit set
- Storage box
- Instruction Manual
Overview
1 Keyless drill chuck
2 Torque adjustment ring
3 Speed selector
4 Direction of rotation switch
5 Battery
6 Battery release button
7 Handgrip area
8 On/off switch
9 Battery Indicator
10 LED working light
11 Drill chuck aperture
12 Bit holder
13 Bits
14 Metal drill bits
15 Wood drill bits
16 Storage bag
17 Charger
18 Bit adapter
19 Chuck ring
20
Functional description
The cordless drill with two-speed gearing
has a 20+1 level torque adjustment, left/
right running, a removable keyless chuck,
a 6-point bitholder and an LED working
light. Please refer to the descriptions below
for information on how the operating ele-
ments work.
Technical data
Cordless Drill .............. PBSPA 12 C3
Motor voltage U .......................... 12 V
Idling speed n
0
1st gear .............................0-460 min
2nd gear .........................0-1750 min
Maximum torque .......................... 35 Nm
Span-chuck ............................ 0.8-10 mm
Weight (with battery) .....approx. 0.945 kg
Weight (accessories only) ...approx. 1.5 kg
Drilling capacity
for wood .......................... max. 19 mm
for steel ........................... max. 10 mm
Sound pressure level
(L ) ....................... 76.8 dB, K
pA
Sound power level
(L ) ......................87.8 dB; K
WA
Vibration (a )
h
Drilling in metal .................. < 2.5 m/s
Screwdriving ...................... < 2.5 m/s
Temperature.......................... max. 50 °C
Charging process .................. 4 - 40 °C
Operation ..........................-20 - 50 °C
Storage ................................ 0 - 45 °C
Battery ...........................................Li-Ion
The specified total vibration value and the
stated noise emission value have been
measured according to a standardised test
method and can be used to compare one
power tool with another.
-1
-1
= 5 dB
pA
= 5 dB
WA
2
2
K= 1.5 m/s 2
