MZR 03
Ref.No.
Ordering number NB
1
4449 0015 00
2
0686 6103 00
5
4449 0023 00
6
0663 9181 00
7
0663 9051 00
10
4449 0013 00
11
0515 0100 09
12
4449 0009 00
13
4449 0017 00
14
4449 0016 00
15
4449 0010 00
16
0502 2231 00
17
0335 2152 00
18
0666 2000 52
20
0502 2231 00
21
4449 0018 00
22
4449 0019 00
23
4449 0020 00
25
4449 0021 00
26
9125 7295 00
33
4449 0014 00
35
0663 2104 31
36
0216 1325 00
37
4449 0012 00
38
4449 0011 00
39
0335 1129 00
42
4449 0006 90
43
4449 0007 00
a Select on assembly / Sélection au montage / Bei Zusammenbau auswählen
/ Selección en el montaje / Selezionare durante il montaggio / Välj i
samband med montering
b Included in Ref. No. 42 / Repris dans la réf. N
enthalten / Incluido en el N1 Ref. 42 / Compresi nel num. di rif. 42 / Ingår i
Ref.No. 42
A Included in seal kit "A" / Repris dans l'ensemble d'étanchéité "A" / In
Dichtungssatz "A" enthalten / Incluido en el juego de juntas "A" / Compresi
nel corredo di tenuta "A" / Ingår i tätningssats "A" 4449 0027 90
Qty
Description
1
Engine case
1
Plug (BSP 3/8")
1
Breather plug
1
O-ring (23.4x3.53)
1
O-ring (7.66x1.78)
1
Crankshaft assembly
2
Needle bearing
(K14x18x10)
1
King rod
3
Queen rod
3
Pivot
1
Spacer
1
Ball bearing
(62065-2RS)
2
Circlip (SgH 62)
A
1
Seal ring (30x62x10)
1
Ball bearing (6205-2RS)
a
1
Spacer
a
1
Spacer
a
1
Spacer
1
Balance weight
1
Screw (M6x8)
1
Flange plate
A
1
O-ring (159.5x3)
8
Screw (M8x25 10.9)
5
Spacer shim
1
Spacer
1
Circlip (SgA 27)
4
Piston assembly
A,b
4
Compression ring
o
42 / In Referenznummer 42
Atlas Copco Tools - No. 9836 1089 01
Ref.No.
Ordering number NB
44
4449 0008 00
45
4449 0005 00
46
4449 0004 00
47
0147 1323 00
48
0337 2622 00
70
4449 0002 00
71
0686 3101 00
75
4449 0025 00
76
4449 0026 00
77
0147 1247 00
78
4449 0001 00
79
0502 1090 82
80
0502 1105 00
81
0335 2143 00
82
4449 0024 00
83
0147 1246 00
84
0338 3111 00
87
4449 0003 00
88
3135 1129 04
ACCESSORIES INCLUDED
73
4449 0022 00
74
0663 9051 00
OPTIONAL ACCESSORIES
(18,35, 4449 0027 90
43,44,46,
76,87
)
Qty
Description
A,b
4
Oil control ring
4
Cylinder
A
4
Gasket
16
Screw (M8x20 8.8)
1
Key (6x6x30)
1
Valve housing
1
Plug (BSP 1/8")
1
Adapter plate
A
1
Gasket
4
Screw (M6x20 8.8)
1
Valve
1
Bearing (6005-RS)
1
Bearing (6005)
1
Circlip (SgH 47)
1
Cover
2
Screw (M6x16 8.8)
1
Key (W 5x19)
A
1
Gasket
4
Screw (M8x25 10.9)
1
Dipstick
1
O-ring (7.66x1.78)
A
1
Seal kit
9
