MZR 1 7 – MZR 24
Ref.
Ordering number NB Qty
No.
1
4449 0066 00
1
4449 0081 00
2
0686 6103 00
5
4449 0023 00
6
0663 9181 00
7
0663 9051 00
10
4449 0063 00
11
0515 3100 14
12
4449 0061 00
13
4449 0069 00
14
4449 0068 00
27
0108 3324 00
28
4449 0062 00
29
4449 0064 00
30
0291 1128 18
31
0508 1100 65
33
4449 0065 00
34
0192 1359 00
35
4449 0067 00
D,E 1
36
0211 1362 00
40
0666 2000 55
D,E 1
42
4449 0058 90
43
4449 0059 00 D,E,a 5
44
4449 0060 00 D,E,a 5
45
4449 0057 00
46
4449 0056 00
D,E 5
47
0147 1957 86
48
0337 8167 00
50
4449 0074 00
51
0554 2251 00
52
4449 0073 00
53
0508 2108 01
54
4449 0071 00
55
0335 2160 00
56
0502 3108 00
57
4449 0072 00
58
0335 1140 00
59
0663 9181 00
D,E 1
b Included in Ref. No. 42 / Repris dans la réf. No 42 / In Referenznummer 42
enthalten / Incluido en el N1 Ref. 42 / Compresi nel num. di rif. 42 /
Ingår i Ref.No. 42
D Included in seal kit "D" / Repris dans l'ensemble d'étanchéité "D" / In
Dichtungssatz "D" enthalten / Incluido en el juego de juntas "D" / Compresi
nel corredo di tenuta "D" / Ingår i tätningssats "D" – 4449 0077 90
E Included in seal kit "E" / Repris dans l'ensemble d'étanchéité "E" / In
Dichtungssatz "E" enthalten / Incluido en el juego de juntas "E" / Compresi
nel corredo di tenuta "E" / Ingår i tätningssats "E" – 4449 0083 90
Description
-17 -24
1
-
Engine case
-
1
Engine case
3
3
Plug (BSP 3/8")
1
1
Breather plug
1
1
O-ring (23.4x3.53)
1
1
O-ring (7.66x1.78)
1
1
Crankshaft assembly
1
1
Needle bearing (NA 6906)
1
1
King rod
4
4
Queen rod
4
4
Pivot
2
2
Spring dowel (6x20)
2
2
Spacer
1
1
Screw
1
1
Lock nut (M8)
2
2
Roller bearing (NF 209)
1
1
Flange plate
5
5
Set screw (M10x16)
1
Gasket
10 10
Screw (M10x25 12.9)
1
Seal ring (44x62x12)
5
5
Piston assembly
5
Compression ring
5
Oil control ring
5
5
Cylinder
5
Gasket
20 20
Screw (M12x35 10.9)
1
1
Key (10x8x60)
1
1
Housing
1
1
Grease nipple
1
1
Shaft
1
1
Roller bearing
(NU 308 ECJ)
1
1
Spacer
2
2
Circlip (SgH 80)
1
1
Ball bearing (6308)
1
1
Spring ring
1
1
Circlip (SgA 40)
1
O-ring (23.4x3.53)
Atlas Copco Tools - No. 9836 1089 01
Ref.
Ordering number NB Qty
No.
60
0211 1363 00
61
4449 0075 00
62
0666 2000 56
63
0147 1246 00
65
4449 0125 00
66
0216 1203 00
70
4449 0054 00
70
4449 0079 00
75
4449 0076 00
76
4449 0051 00
D,E 1
77
0147 1363 07
77
0211 1363 00
78
4449 0053 00
78
4449 0078 00
79
0502 1090 83
79
0502 1090 84
80
0502 1110 00
80
0502 2111 00
81
0335 2160 00
81
0335 2169 00
82
4449 0070 00
82
4449 0082 00
83
3135 1129 04
85
0102 0410 00
86
0101 1951 20
87
4449 0055 00
D
87
4449 0080 00
E
88
0147 1958 27
88
0147 1363 07
89
0653 1066 00
89
0653 1056 00
OPTIONAL ACCESSORIES
(35,40, 4449 0077 90
D
43,44,46,
59,76,87)
(35,40, 4449 0083 90
E
43,44,46,
59,76,87)
Description
-17 -24
5
5
Screw (M10x30 12.9)
1
1
Cover
1
1
Seal ring (48x62x8)
5
5
Screw (M6x16 8.8)
-
1
Bearing cap
-
4
Screw (M5x8 10.9)
1
-
Valve housing
-
1
Valve housing
1
1
Adapter plate
1
Gasket
4
-
Screw (M10x30 10.9)
-
4
Screw (M10x30 12.9)
1
-
Valve
-
1
Valve
1
-
Ball bearing (6010-RS)
-
1
Ball bearing (6211-RS)
1
-
Bearing (6010)
-
1
Bearing (6211)
1
-
Circlip (SgH 80)
-
1
Circlip (SgH 100)
1
-
Cover
-
1
Cover
4
4
Screw (M8x25 10.9)
1
1
Pin (10m6x30)
1
1
Pin (12m6x35)
1
-
Gasket
-
1
Gasket
5
-
Screw (M12x30 10.9)
-
10
Screw (M10x30 10.9)
5
-
Washer (13/24x1)
-
10
Washer (12/20x1.5)
1
-
Seal kit
-
1
Seal kit
13
