KPX55LIKTA - KPX55ELIKTA
INDEX

7.8 ARM FITTING

- Move the carriages to a height of 70-80 cm
- Fit in the long and short arms:
disassemble the toothed wheel (1) by unscrewing the respective screws; remove the pin (2); insert the arm inside the carriage wings
and reassemble the pin (2) and toothed wheel (1), securing it with the screws.

7.9 USE OF ACCESSORIES

The lift may be used with accessories to facilitate the operator's work.
Only original manufacturer's accessories may be used.
2
1
EN_24 0473-M003-0
