Robot doesn't resume cleaning
after charging
Robot doesn't return to charging
dock after being moved
Specifications
Robot
Model
Battery
Charging Time
Wireless Connectivity
Rated Voltage
Rated Power
Operation Frequency
Maximum Output Power
Charging Dock
Model
Rated Input
Rated Output
Under normal use of condition, this equipment should be kept a separation distance of at
least 20cm between the antenna and the body of the user.
Make sure the mop pad is installed correctly
according to the user manual.
Clean the blowhole on the top of the water tank.
Make sure the robot is not set to Do Not Disturb
mode, which will prevent it from resuming cleaning.
The robot does not resume cleaning when it is
manually recharged or placed onto the base.
Moving the robot may cause it to re-position itself or
re-map its surroundings. If the robot is too far from
the charging dock, it might be able to automatically
return on its own, in which case you need to
manually place the robot onto the charging dock.
RLS5-BL1
5200 mAh (Battery Nominal Capacity)
Approx. 6 hours
Wi-Fi IEEE 802.11b/g/n 2.4 GHz
14.4
40W
2400-2483.5 MHz
< 20 dBm
RCS0
100-240 V ~ 50/60 Hz 0.5 A
19.8 V 1A
