1.8.3 Additional USB 2.0 Port Headers
Each header supports 2x additional USB 2.0 ports by connecting bracket or cable to the rear I/O
panel or the front-mounted USB ports of your chassis.
Make sure the connecting cable bears the same pin assignment.
※
1.8.4 Additional IEEE 1394 Port Header
Each header supports 1x additional IEEE 1394 port by connecting bracket or cable to the rear
I/O panel or the front-mounted IEEE 1394 port of your chassis.
Make sure the connecting cable bears the same pin assignment.
※
1-16
All manuals and user guides at all-guides.com
Pin
1
3
5
7
Pin
1
3
5
7
Pin Assignment
Pin
5VDUAL
2
Data0 -
4
Data0 +
6
Ground
8
10
Pin Assignment
Pin
TPA0 +
2
Ground
4
TPB0 +
6
+12V
8
10
Pin Assignment
5VDUAL
Data1 -
Data1 +
Ground
NC
Pin Assignment
TPA0 -
Ground
TPB0 -
+12V
Ground
IX38 QuadGT
