1.6.4 Extra Fan Set installation
Proceed with extremely care while installing the extra fan set. DO NOT damage
※
the motherboard components.
As shown in this photo, it is possible to attach
one mini 40mm(W) x 40mm (H) x 10mm(D)
cooling fan (not included in this motherboard
package) aside the chipset heatsink to increase
the heat dissipating efficiency.
Connect the fan power plug to one of the fan
power connectors.
As shown in this photo, it is possible to attach
one mini 40mm(W) x 40mm (H) x 10mm(D)
cooling fan (not included in this motherboard
package) on top of the PWM heatsink to
increase the heat dissipating efficiency.
Enclosed in the motherboard package you can
find a pair of retention clips. This bundled
accessory is used to hold the fan itself.
Connect the fan power plug to one of the fan
power connectors.
IX38 QuadGT
All manuals and user guides at all-guides.com
1-9
