2.1 μGuru
Utility
There are two setup menus in this μGuru utility. You may switch between these two by clicking
the left or right arrow key on keyboard:
2.1.1 OC Guru
OC Guru
Intel(R) Core(TM)2 CPU
Frequency : 1904MHz
CPU Operating Speed
- External Clock
- Multiplier Factor
X - Estimated New CPU Clock
- DDR2 Speed (CPU : DDR2)
- PCI Express Clock
► Voltages Control
► Power Cycle Statistics
:Move Enter:Select +/-/PU/PD:Value F8:OC On The Fly F10:Save ESC:Exit
Intel(R) Core(TM)2 CPU
This item displays the CPU model name installed on this motherboard.
The model name displayed in this item will be replaced according to the actual
※
type of CPU you installed.
Frequency
This item displays the current CPU frequency.
CPU Operating Speed
This item displays the CPU operating speed according to the type and speed of your CPU. You
can also select the [User Define] option to enter the manual option.
User Define:
The wrong settings of the multiplier and external clock in certain
※
circumstances may cause CPU damage. Setting the working frequency higher
than the PCI chipset or processor specs, may cause abnormal memory module
functioning, system hangs, hard disk drive data lose, abnormal functioning of
the VGA card, or abnormal functioning with other add-on cards. Using
non-specification settings for your CPU is not the intention of this explanation.
These should be used for engineering testing, not for normal applications.
There will be no guaranty for the settings beyond specification. Any damage of
※
any component on this motherboard or peripherals resulting therein is not our
responsibility.
-
External Clock
This item selects the external clock frequency. Due to the specification limit of the CPU you
installed, the speed you set over its standard bus speed is supported, but not guaranteed.
2-2
All manuals and user guides at all-guides.com
μGuru Utility v1.01C
6320 @ 1.86GHz
1866(266)
272MHz
X 7
1904MHz
Default (DDR2-1088)
100MHz
Press Enter
Press Enter
Item Help ►
IX38 QuadGT
