R 360
STARTER SET
6. Technical data
6.1 CR0501
Housing
Dimensions of the Housing
Mounting position
Device connection
Operating temperature
Storage temperature
Protection rating
Protection class
Air humidity
Supply voltage
Power consumption
Processor
Display
Device monitoring
Memory
Interface
32
PAGE
All manuals and user guides at all-guides.com
enclosed, shielded metal housing
with flange fixing
225 x 153 x 43 mm (WxHxD) without connector
240 x 153 x 43 mm (WxHxD) with connector
preferably vertical
as an alternative horizontal
55-pole connector, latched, protected against reverse
polarity, type AMP with crimp contacts, AMP junior
timer 0.5/2.5 mm²
-30°C ... +75°C
-40°C ... +90°C
IP 67 (protection for the connector, depending on the
cable version)
III
≤ 90% rel. air humidity, non condensing
(perm. altitude 2000 m)
U
nominal 24 V DC (22...30 V DC)
B
residual ripple:
reset in case of undervoltage: ≤ +12.0 V
overvoltage:
approx. 10 VA, without external load
CMOS microcontroller C 167 C
three-colour LED red/green/orange
for the status and fault indication
8-bit microcontroller to monitor C 167 C
(extended watchdog function)
undervoltage and overvoltage monitoring
checksum test for program and system
excess temperature monitoring
256 kByte program memory
64 kByte data memory
256 Byte auto-save data memory (protected against
power failure)
Full CAN bus, version 2.0 (ISO/DIS-11898)
baud rate:
device class:
serial interface RS232C, 9.6 kBaud
number of participants: 2
≤ 1.5 Vpp, f ≤ 50 Hz
≤ +36.0 V für t ≤ 10 s
10 KBits/s ... 1 MBits/s
CANopen:
master/slave
CAN:
Full CAN
