4.1 Hardware

Connect the 55-pole AMP connector to the controller.
Proceed as shown on the schematic drawing:
A: Place the AMP connector into the guiding slot of the controller.
B: Swivel the AMP connector onto the connector of the controller.
(the guiding slot fixes the AMP connector and serves as a pivot)
C: Place the locking clip over the AMP connector.
(The locking clip presses the AMP connector onto the connector of the
controller)
Insert the 9-pole RS232 plug into the free serial interface of your PC.
Connect the 2-pole connector with the plug-in power supply.
Insert the plug-in power supply into the wall socket (230 V, 50 Hz)
Note:
The 5-pole socket "CAN bus" is for the connection of further CAN compo-
nents and remains unconnected.

4.2 Software

1. Start Windows and insert the CD-ROM into your CD drive.
2. If the "autostart function" of your CD-ROM drive is active,
the ecolog100
3. Follow the instructions of the setup program.
During the set-up you can activate or deactivate the installation of Acrobat
Reader and the manuals.
