Function and features

• AS-i profile: S-7.A.E
• maximum number of modules per master: 31 (62 with AS-i master 2.1)
• AS-interface version 2.1

Operating and display elements

Mounting
Mount the module onto the wired module lower part of the AS-i net-
work, tightening torque 0.8Nm.

Technical data

You can download the data sheet from the Internet address
www.ifm-electronic.com if required.

Electrical connection

Connect the plugs of the sensors / actuators to the M12 sockets. Cover
any unused sockets with the protective caps (AC3004) to guarantee
protection rating IP67.
6
PAGE
45
LEDs
fixture infrared adapter
labels
2 sockets M12
