SPL Track One Mk3 Bedienungsanleitung Seite 10

Track One Mk3 – Manual
Specifications
Analog inputs & output; XLR & TRS Jack (all balanced, except INSTR./LINE IN: unbalanced)
Maximum input gain (Mic, +8 dB – +63 dB)
Maximaler Eingangs (Line, -12 dB – +22 dB)
Maximaler Eingangs (Instrument, 0 dB – +35 dB)
Input impedance (Instrument)
Input impedance (Line)
Input impedance (Instrument)
Frequency range (Mic)
Noise (A-weighted, Mic Preamp, 150 Ω, 30 dB Gain)
Noise (A-weighted, Mic Preamp, 150 Ω, 50 dB Gain)
Nois ((A-weighted, Mic Preamp, 150 Ω, 64 dB Gain)
Noise (A-weighted, Line/Instr Preamp, 0 dB Gain)
Ra usc(A-weighted, Line/Instr Preamp, 10 dB Gain)
Rau sc(A-weighted, Line/Instr Preamp, 22 dB Gain)
Equivalent Input Noise (EIN)
Common mode rejection (1 kHz)
THD+N Ratio (1 kHz), Mic 30 dB Gain
THD+N Ratio (1 kHz), Mic 50 dB Gain
THD+N Ratio (1 kHz), Mic 64 dB Gain (Max.)
THD+N Ratio (1 kHz), Line 0 dB Gain
THD+N Ratio (1 kHz), Line 10 dB Gain
THD+N Ratio (1 kHz), Line 22 dB Gain
THD+N Ratio (1 kHz), Instrument 0 dB Gain
THD+N Ratio (1 kHz), (100 kΩ source impedance)
Internal Linear Power Supply with Shielded Toroidal Transformer
Operating voltage for analog audio
Phantom power
Mains Power Supply
Mains voltage (selectable)
Fuse for 230 V
Fuse for 115 V
Power consumption
10
Reference: 0 dBu = 0.775V. All specifications are subject to change without notice.
10.6 dBu (bei +8 dB GAIN)
33.5 dBu (bei +8 dB GAIN)
21.5 dBu (bei +8 dB GAIN)
10 kΩ
47 kΩ
1.1 MΩ
10 Hz – 195 kHz
-94.5 dBu
-79 dBu
-65 dBu
-97 dBu
-90.5 dBu
-79 dBu
-126.8 dBu
< 80 dB
0.004 %
0.014 %
0.029 %
0.0021 %
0.0016 %
0.0045 %
0.0061 %
+/- 15 V
48 V
230 V AC / 50; 115 V AC / 60 Hz
T 312 mA
T 630 mA
max. 7.6 VA
