When fitting and removing the parts, proceed as shown on Fig. 2, 3 and
fixing elements and buttons for fitting, consequently, the fitting and removing procedure is
intuitive.
4.2 INSTALLATION OF THE CHARGING DOCK WITH THE DIRT
EXTRACTION UNIT
1. Place the charging dock with the dirt extraction unit on the floor, at a distance of approx.
6 cm from the wall. Make sure there is enough space around the vacuum cleaner (min
0.5 cm on the sides and min 1.5 m in front). Avoid exposure of the charging dock with
the dust extraction unit to sun.
2. Connect supply cable F to the charging dock, and then to the mains. The D1 indicator
light comes on. Orange light D1 lights up. If there is no dust bag in the charging station,
or it is incorrectly positioned, the D1 light starts flashing red.
6 cm
– If the battery has been discharged, place the device into the charging dock manually.
– After connection to the charging dock, the device will be switched on automatically.
– During charging and connection to the charging dock, the device cannot be switched off.
– The cleaning operation must always be started with the robot vacuum cleaner
in the charging dock.
5. VACCUM CLEANER USE
The vacuum cleaner can be controlled in simplified mode only using buttons A6 and A7
or the remote control. In order to use all device´s functions, you will have to install and use
smart app ETA Smart, allowing extension of vacuum cleaner functionality and increased
user comfort.
All other information, operating instructions of the app, instructions and hints for successful
pairing with home network can be found at:
The app is available from Apple Store or Google Play database.
Remarks
www.etasince1943.com/robot
EN - 45
EN
4.
Use standard
