6. Optional Accessories

• Mounting Bush DZ-811 is optionally available to mount the measuring unit on Gauge
Stand DZ-501.
• Extension cable
CE22-01: 1 m, CE22-03: 3 m, CE22-05: 5 m, CE22-10: 10 m
13.6
Bare wire colors
Color Red
Signal +Vcc
CK-T12: 1 m, CK-T13: 3 m, CK-T14: 5 m, CK-T15: 10 m
13
4.8
6.2
8
(E)
41.5
5.5
5.5
30.5
White Blue
0 V A
Cable length: 1, 3, 5, 10 m
24.3
35.5
49.5
14
Cable length: 1, 3, 5, 10 m
Yellow Orange
A B
5.5
14
50
Gray Green Violet
B Z
13.6
5.5
30.5
41.5
Unit: mm
Z
