6. Optional Accessories

• Mounting Bush DZ-811 is optionally available to mount the measuring unit on Gauge
Stand DZ-501.
• Bellows set
DZ830BL (For DK830SLR)
Bellows
Extension
spindle
• Extension cable
CE22-01: 1 m, CE22-03: 3 m, CE22-05: 5 m, CE22-10: 10 m
55.5
41.5
CK-T12: 1 m, CK-T13: 3 m, CK-T14: 5 m, CK-T15: 10 m
13
4.8
6.2 24.3
35.5
71
2 19
27
22
M2.5×0.45
21
M2.5×0.45
1
6
Cable length: 1, 3, 5, 10 m
Cable length: 1, 3, 5, 10 m
49.5
DZ830BV (For DK830SVR)
27
22
21
M2.5×0.45
1
6
Bare wire colors
50 Signal
+Vcc
0 V
A
A
B
B
Z
Z
5.5
30.5
14
41.5
71
M2.5×0.45
Unit: mm
Color
Red
White
Blue
Yellow
Orange
Gray
Green
Violet
13.6
5.5
Unit: mm
7
(E)
