Operating instructions - TEKA–filtoo
36

1. Commissioning

1. 1.

Unpacking the filtoo

The filtoo is delivery completely packed in a carton. The enclosed intake element (suction arm or suction
hose) is separately packed.
Attention!
The intake element must be fitted to the device before the start-up. Always make sure that
the device is in a safe position and that the brakes at the swivel castors are pulled.

1. 2. Connecting the intake elements

1. 2. 1. Use of a suction arm

The suction arm is fixed with the help of the rotary flange (pos. 19),
screws (pos. 17) and lock washers (pos. 18) at the upper connection
opening (pos. 4) of the housing.
For further information, see the separate manual for the suction
arm.
17
18
19
