3 .3 Overhead suspension 3080

10
9
8
1 Frame
2 Mount for reel
3 Reel rollers
4 Power pack 3080 holder
5 OHS closure chain guide
6 Hanger
7 ATS3080
8 Balancer
9 Guide roller
10 Screw links
The Overhead suspension 3080 enables the ATS3080
to be mounted to a hanger
Overhead suspension 3080 is suspended from screw
links .
11
The user can guide the ATS3080
virtually no load and carry out the binding.
Assembly Instructions Overhead suspension 3080 • 03-2017 • v02 • 102-01013
7
. The
6
to the bundle with
7

Transport, scope of supply and storage

4 Transport, scope of supply and storage

4 .1 Transporting the device

Always use the supplied box to transport the
Overhead suspension 3080.
The components of the Overhead suspension 3080 are
1
packaged for transport.
2
NOTE
Components not correctly packed are subject to a risk of
damage in transit.
3
f Do not unpack components until just before they are
going to be installed.
4

4 .2 Scope of supply

Name
Assembly Instructions
5
Hanger
Balancer
Spiral cable 1 .2 m
OHS closure chain guide
6
Screw link, 2 of

4 .3 Disposal

7
The operating company is under obligation to ensure
that at the end of its useful life, the ATS3080 and the
components including the accessories are disposed of in
accordance with the applicable local regulations. End-of-
life (EOL) disposal of the ATS3080 and individual
subassemblies and the disposal of consumables and
auxiliaries are subject in part to statutory regulations.
The appropriate local authorities will provide detailed
information on request.
f Always dispose of packaging materials in accordance
with the currently valid materials-disposal and
environmental protection regulations.
f Always take materials, production waste and
consumables for disposal to certified collection points.
f Contact the manufacturer for advice if there is any lack
of clarity regarding disposal.
