ControlLogix
Control Tags
chX = Kanal X; LB = Low Byte; HB = High Byte
Zumutbare Änderungen aufgrund technischer Verbesserungen vorbehalten.
Pepperl+Fuchs GmbH · 68301 Mannheim · Telefon (06 21) 7 76-11 11 · Telefax (06 21) 7 76 27-11 11 · Internet http://www.pepperl-fuchs.com
Anhang: Integration in eine Rockwell SPS
Tag Bit Nr. AS-i-Adresse
0-7
8-15
1:I.Data(8)
16-23
24-31
0-7
8-15
1:I.Data(9)
16-23
24-31
0-7
8-15
1:I.Data(10)
16-23
24-31
0-7
8-15
1:I.Data(11)
16-23
24-31
0-7
8-15
1:I.Data(12)
16-23
24-31
0-7
8-15
1:I.Data(13)
16-23
24-31
AS-i DeviceNet-Gateway
16-Bit AS-i-Slaves
Tag
31 ch1 LB
31 ch1 HB
1:O.Data(8)
31 ch2 LB
31 ch2 HB
31 ch3 LB
31 ch3 HB
1:O.Data(9)
31 ch4 LB
31 ch4 HB
30 ch1 LB
30 ch1 HB
1:O.Data(10)
30 ch2 LB
30 ch2 HB
30 ch3 LB
30 ch3 HB
14:O.Data(11)
30 ch4 LB
30 ch4 HB
29 ch1 LB
29 ch1 HB
1:O.Data(12)
29 ch2 LB
29 ch2 HB
29 ch3 LB
29 ch3 HB
1:O.Data(13)
29 ch4 LB
29 ch4 HB
Copyright Pepperl+Fuchs, Printed in Germany
Bit Nr. AS-i-Adresse
0-7 31 ch1 LB
8-15 31 ch1 HB
16-23 31 ch2 LB
24-31 31 ch2 HB
0-7 31 ch3 LB
8-15 31 ch3 HB
16-23 31 ch4 LB
24-31 31 ch4 HB
0-7 30 ch1 LB
8-15 30 ch1 HB
16-23 30 ch2 LB
24-31 30 ch2 HB
0-7 30 ch3 LB
8-15 30 ch3 HB
16-23 30 ch4 LB
24-31 30 ch4 HB
0-7 29 ch1 LB
8-15 29 ch1 HB
16-23 29 ch2 LB
24-31 29 ch2 HB
0-7 29 ch3 LB
8-15 29 ch3 HB
16-23 29 ch4 LB
24-31 29 ch4 HB
