ETOILE CONSOLE WASHBASIN PACKING LIST
K. Ceramic basin (x1)
L. "S"shaped brackets (x2)
E
N
G
(Screws and rawplugs not provided by Devon&Devon)
K
L
20
ASSEMBLY INSTRUCTIONS
1) Check that the wall and floor are perpendicular.
CAUTION:
AFTER REMOVING THE ITEMS FROM THE PACKING STRUCTURE, PLACE THE STRUCTURE ON THE
GROUND EITHER ON A CARDBOARD OR ON ANOTHER MATERIAL SUITABLE TO KEEP THE PRODUCT
INTACT.
2) Screw the threaded bars (E) into the structure holding the towel rods (A).
E
A
E
21
E
N
G
