Before You Begin; Tools Needed - Devon & Devon Etoile Console Montageanleitung

WARNINGS
Make sure that the parts are intact. In case of defect or doubt, contact the retailer.
Assembly must be carried out following the instructions indicated below.
The company accepts no liability for installations that do not comply with current
standards and for assembly and maintenance that do not comply with these warnings
and instructions.
All packaging (boxes, plastic bags, polystyrene, etc...) must be kept
out of the reach of children as it can be a source of danger (risk of
suffocation, abrasions, etc...).

BEFORE YOU BEGIN

- Please check the existing layout of the system required before assembly.
- Verify the presence of all items inside the package using the Packing List included
in the following page. Also verify that none of the components show visible defects.
- If you should notice any defects please contact Devon&Devon immediately.
E
- To assemble this product the presence of at least two people is necessary.
N
G
- The assembly instructions are supplied with the assumption that the walls are
perpendicular to the floor and that their structure is suitable to support the product.

TOOLS NEEDED

(NOT SUPPLIED BY DEVON&DEVON)
A. Silicon
B. Drill/ Electric screw-driver
C. Level
D. 6mm drill bit
E. Meter stick
C
F. Pencil
A
B
E
18
ETOILE CONSOLE STRUCTURE PACKING LIST
A. Metal structure (x1)
B. Glass shelf (x1)
C. Screws and rawlplugs to fasten the metal structure to the wall (x4)
D. Legs (x2)
E. Threaded rods (x2)
F. Small feet (x2)
G. Adjustable supports for the basin (x2)
H. Fixed supports for the basin (x2)
I. Screws and rawlplugs to fasten the supports of the glass shelf (x2)
J. Supports for the glass shelf (x2)
C
x4
D
D
E
F
F
A
x4
G H I
19
E
N
G
B
J
