8.6 REPLACING BULBS
8.6.1 Type "l" - Incandescent light bulbs
• The bulbs (18W) have a bayonet fitting
and are installed in the bulb holder,
which can be taken out by turning it
anti-clockwise with pliers (fig. 48).
8.6.2 Type "ll" - LED light bulbs
• Loosen the lock nut (fig. 49.A) and
remove the connector (fig. 49.B).
Remove the LED illuminator (fig. 49.C),
secured by screws (fig. 49.D).
8.6.3 Type "III" - LED light bulbs
1. Raise the bonnet and remove
the connector (fig. 50.A).
2. Detach the cotter pin (fig. 50.B) and
slide the bonnet off laterally.
3. Detach the LED light bulb cables (fig.
51.A), undo the screws (fig. 51.B)
and release the tabs (fig. 51.C).
4. Raise and release the upper part
of the bonnet (fig. 52.A).
5. Undo the screws (fig. 53.A) and replace
the LED headlights (fig. 53.B).
6. To replace the bonnet, repeat the
above procedure in reverse order.
8.7 REAR DRIVE UNIT
This is a sealed single unit that does not require
maintenance. It is permanently lubricated and its
lubricant does not need changing or topping up.
8.8 REGULATING THE GRASS
CATCHER RETAINING
PAWL SPRING
If the grass catcher bag tends to jolt or
open unexpectedly while driving over
uneven ground, or if it is difficult to
recouple the retaining pawl after emptying
the bag, it may be necessary to adjust
the tension on the spring (fig. 54.A).
Adjust the mounting point by selecting the
hole (fig. 54.B) that provides the desired result.
9. STORAGE
When you intend to put your machine
away for more than 30 days:
1. Wait for the engine to cool
2. Disconnect the battery cables and
store it in a cool and dry place.
3. Empty the fuel tank (par. 7.2.2) and follow
all the instructions in the engine manual.
4. Clean the machine thoroughly.
5. Check the machine for any
damage. If necessary, contact the
Authorised Service Centre.
6. Store the machine:
– with the cutting device assembly lowered
– in a dry place
– protected from inclement weather
– covered with a sheet where
possible (par. 15.4)
– in a place where children cannot get to it
– making sure that keys or tools used
for maintenance are removed.
Before starting to use the machine again:
• check that there are no fuel leaks from
the tubes, fuel stopcock or carburettor:
• prepare the machine as described in
chapter "6. Using the machine" .
10. HANDLING AND TRANSPORTATION
• When handling the machine, always:
– disengage the cutting device;
– bring the cutting device assembly
to the highest position;
– stop the engine;
• When transporting the machine
on a vehicle or trailer, always:
– use an access ramp of suitable
strength, width and length;
– load the machine with the engine
switched off, with the key removed from
the ignition, without a driver and pushed
by an adequate number of people;
– close the fuel tap (if provided);
– lower the cutting -device assembly;
– engage the parking brake;
– position it so that it does not
cause a hazard to anyone;
– fasten firmly to the device of transport using
ropes or chains to prevent it from tipping
over causing damage and fuel leaks.
11. ASSISTANCE AND REPAIRS
This manual provides all the necessary
information to run the machine and for correct
basic maintenance operations which can
be performed by the user. Any regulations
and maintenance operations not described
herein must be carried out by your Dealer
EN - 25
