comply with these instructions to
avoid serious risks or hazards.
For storage and transport purposes, some
components of the machine are not installed
in the factory and have to be assembled after
unpacking. Follow the instructions below.
Unpacking and completing the assembly
should be done on a flat and stable surface,
with enough space for machine handling
and its packaging, always making use of
suitable equipment. Do not use the machine
until all the indications provided in the
"ASSEMBLY" section have been carried out.

4.1 ASSEMBLY COMPONENTS

The packaging holds the components needed
for assembly as listed in the table below:
Description
1 Steering wheel
2 Dashboard cover and steering
wheel assembly parts
3 Driving seat
4 Front bumper (if fitted)
5 Bag with mounting screws etc. and
instructions (models with rear collector
only)
6 Grass catcher bag supports and asso-
ciated attachments (models with rear
collector only)
7 Side discharge chute (for models with
side discharge only)
8 Cutting device assembly side strength-
eners (if fitted).
9 Envelope containing:
- the instruction manuals and documents
- driving seat assembly screws
- side discharge chute assembly fittings
(for models with side discharge only)
- the connection screws for the battery
cables
- 2 starter keys
- 1 spare 10 A fuse
10 Mulching kit (models with side discharge
function only) (if fitted).

4.1.1 Unpacking

1. Carefully open the packaging, paying
attention not to lose components.
2. Consult the documentation in the
box, including these instructions.
3. Remove all the unassembled
parts from the box.
4. Remove the machine from the packaging
taking the following precautions:
– move the cutting device assembly
to its maximum height (par. 5.11) to
protect it against damage when the
machine is lifted off the base pallet;
– Lift the machine off the base pallet.
5. Move the front drive release lever to
the released position (par. 5.4).
4.2 STEERING WHEEL ASSEMBLY
1. Put the machine on a flat surface
and straighten the front wheels.
2. Using a screwdriver, remove the central cap
(fig. 3.B) from the steering wheel (fig. 3.A).
3. Fit the steering wheel (fig. 3.A) onto the
protruding shaft (fig. 3.C), rotate it so that the
spokes are facing the seat and then push
it so that the steering wheel hub couples
with the protruding end of the pin (fig. 3.D).
4. Secure the steering wheel using the screw
(fig. 3.E) and the washers (fig. 3.F) e (fig.
3.G) supplied, in the indicated sequence.
5. Tighten the screw (fig. 3.E) fully
using a socket wrench.
6. Replace the cap on the steering wheel (fig.
3.B) inserting it so that it clicks into place.
4.3 SEAT ASSEMBLY
Pull the regulator lever up (fig. 4.C) and
slide the seat (fig. 4.A) into the guide (fig.
4.B) from the steering wheel side, until
it clicks into one of the six positions.
At this point, the seat has been mounted
securely, so that it cannot be removed again
without pressing the release lever (fig. 4.D).
4.4 MOUNTING AND CONNECTING
THE BATTERY
The battery (fig. 5.A) is housed under the
seat and secured by a spring (fig. 5.B).
1. First connect the red wire (fig. 5.C) to
the positive pole (+) and then the black
wire (fig. 5.D) to the negative pole (–),
using the screws supplied as shown.
2. Mount the battery retaining spring (fig. 5.B),
making sure that the cables are routed
correctly in front of the battery, so that they
are not pinched by the spring (fig. 5.B).
IMPORTANT Always fully charge the
battery according to the instructions
in the battery booklet.
