3.

Start up

3.1 Lifting and carrying

Model
FV30
FV37
FV45
FV55

3.2 Dimensions

H
D
Fig. 3.2 Dimension drawing FV30-55.
14
All lifting should be carried out using a forklift truck with a carrying capacity
suited to the compressor. Lifting may be carried out with loading cranes,
winches and other machinery, using a crossbeam with the right length. Lo-
cal safety guidelines for lifting have to be observed.
G
A
A,mm B, mm
332
775
540
L
D
B
C
C, mm
185
Model
FV30
FV37
FV45
FV55
FV30
FV37
FV45
FV55
For transport with a forklift
truck, use the rigging holes
in the frame. The compressor
has slotted rigging holes with
width C – fig. 3.1. Move the
compressor carefully.
Fig. 3.1 Lifting and carrying
FV30-55.
D, mm
292
150
Compressor dimensions
Length Width Height
L, mm D, mm H,mm
1400 1000 1500
1650 1250 1720
Packaging dimensions
1600 1100 1750
1850 1350 1950
G, mm
1200
1300
Weight,
kg
725
765
1015
1190
755
795
1055
1240
