The adding mode is set if the chosen start count value SC is lower
than preset values P1 and P2. The subtracting mode is set if the
chosen start count value SC is greater than preset values P1 and P2.
The subtracting mode is impractical in operating modes 2 (parallel
comparison) and 3 (self-adjusting preset).

6 Technical data

Technical data - electrical ratings
Voltage supply
Power consumption
Sensor supply
Display
Number of digits
Digit height
Function
Scaling factor
Multitplier / batch counter
Count modes
Counting frequency
Operating modes
Data memory
Reset
Outputs electronic
Outputs relay
Output holding time
Interfaces
Standard
DIN EN 61010-1
Emitted interference
Interference immunity
www.baumer.com
24/48 VAC ±10 % (50/60 Hz)
85...265 VAC (50/60 Hz)
24 VDC ±10 %, 5 % RW
15 VA, 8 W
24/48 VAC: 12...26 VDC/80 mA
85...265 VAC: 24 VDC ±20 %/200 mA
24 VDC: 24 VDC ±20 %/200 mA
LED, 7-segment display
8-digits - totalizer
6-digits - main counter, batch counter,
tachometer, hour counter
7 .6 mm
Preset counter
Main counter with 2 presets
Batch counter with 1 preset
Totalizer
Hour counter
0.0001...9999.99
1...99
Adding or subtracting
A-B (difference counting)
A+B total (parallel counting)
Up/Down
A 90° B phase evaluation
15 Hz, 25 Hz, 10 kHz programmable
Step preset, Main preset,
Parallel alignment, Trailing preset
>10 years in EEPROM
Button, electric or automatic
NPN / PNP transistor switch
Potential-free change-over contact for
main counter Normally open/closed
potentialfree for B1
0.01...99.99 s
RS232, RS422, RS485
Protection class II
Overvoltage category II
Pollution degree 2
DIN EN 61000-6-4
DIN EN 61000-6-2
