Incorrect code If an incorrect code has been input:
Correct code unknown If the correct code is not known, return the counter to the factory.
Correct code ➜ When the correct code has been input, press the
Key 0 ... 9
Change of value via the numerical keypad.
Key
Operating mode: Deletes the display.
Programing mode: Counted value reset to zero or to the main counter
start count value. Reset of possible programmed operating continious
contacts. Selection of output signals on continious signal (latch).
Key
Operating mode: Transfer from any display to a parameter corre-
sponding the selection in line 35 for rapid preset value input.
In conjunction with the
Key +/-
Operating mode: The simultaneous operation of the +/- and the 2
key starts the test routine; the power supply must be switched on
at the same time. Operating-/Programing mode: Input of a +/ - sign.
The method of accessing the programming mode is described be-
low, together with the four programming segments in the order in
which they are used.
To access programming
➜ Press the key.
● The system switches from operating to the programming mode.
➜ Press the key. Code is displayed.
The code applies to programming segments 1-4.
➜ Input code and press the
No code is entered before delivery.
● Error appears in the display when the
counter reverts to the operating mode.
➜ Press the key.
➜ Press the key.
➜ Input the correct code.
● The programming segments are now called up in succession.
www.baumer.com
key, transfer to programming mode.
key.
key is pressed. The
NE212
key.
