NE212
Operating mode In the operating mode:
Parameter readout Select accessible parameters by the
Parameter input 1. Upon pressing the
SC
SC
Change preset value 1 Press the
SC
46

4 Operating mode

The operation and use of the counter are described in the section.
● As soon as the power supply has been switched on, the counter
is automatically set to the operating mode.
- the current counter status can be read and reset;
- the preset values for the main and batch counters can be read;
- the start count value can be read;
- the current totalizing counter can be read and reset;
- the current status of the batch counter can be read and reset;
- the time meter can be read.
All the parameters can be disabled in the programming mode
(line 11 to 18).
Key functions
Pay attention to the LED symbols.
2. Use the
display.
3. Enter new parameter by the 10-figure keypad, the old parameter
will be deleted. To enter more parameters repeat steps 2 and 3.
4. Confirm the entered parameter by pressing the
is no confirmation within 15 seconds the previous parameters
will remain.
The key comprises a memory function.
This means: after confirmation the parameter indicated at the
first operation will appear on the display again.
Current main counter status
The current counter status is displayed in the operating mode; no
keying necessary.
➜ Read the counter status.
Reset Resetting must be enabled in the programming mode (line 11).
➜ Press the
Main counter preset values
The preset value functions must be enabled in the programming
mode (line 12 and 13).
➜ Press the
➜ Read preset value P1.
● LED P1 flashes.
➜ Input the new preset value P1 via the numerical keypad; the old
value will be deleted.
➜ Press the
➜ Press the
➜ Read preset value P2.
➜ Press the
www.baumer.com
key, the LED is flashing.
key until the desired parameter appears on the
key.
key.
key.
key. The change is completed.
key.
key.
key.
key. If there
