Appliance/Control Panel - Pkm GSP12A++7TI Bedienungsanleitung

3. Appliance/Control Panel

1 Upper dish rack
3 Lower dish rack
5 Container for detergent, tabs and
rinse aid
7 Spray arms
9 Water supply hose
1 On/Off
Display: Indicates remaining time and current status (operation, time delay,
2
error codes, etc.).
3 Timer button: To activate the timer function
4 Extra-Dry indicator: Extra-Dry function has been selected.
5 Programme button: Setting of the desired programme.
Front
2 Inner pipe
4 Salt container
6 Cup tray
8 Filter assembly
10 Water drain hose
57
Back
