Speaker Output; Headphone Output - Shure Microflex Complete Wireless Bedienungsanleitung

Type
TRRS 3.5 mm female socket
Pin Assignments
CTIA/AHJ Standard Pinout
Tip= Left side earpiece, Ring 1= Right side earpiece, Ring2= Ground, Sleeve= Microphone

Speaker Output

Nominal Output Level
72 dB SPL at 0.5 m
Measured with an SPL meter using A-weighting and fast averaging
Maximum Output Level
89 dB SPL at 0.5 m
3% THD+N
Frequency Response
220 Hz­ 15 kHz (±10 dB)
Audio Injected at Dante Input
Total Harmonic Distortion
1%, typical
Audio Injected at Dante Input
Dynamic Range
94 dBA­weighted, 91 dB Unweighted, typical

Headphone Output

Maximum Output Level
2.1 dBV
1% THD+N. Audio Injected at Dante Input.
Frequency Response
100 Hz­ 20 kHz (+0.5 dB/­3 dB)
Audio Injected at Dante Input
Total Harmonic Distortion
0.04%, typical
Audio Injected at Dante Input
Dynamic Range
101 dB A­weighted, 99 dB Unweighted, typical
