Important: Always perform a "walk around" test to verify coverage before using a wireless system during a speech or perfor­
mance. Experiment with placement to find the optimum location.

Requirements Checklist

Make sure your equipment meets these requirements before installing the system:
• Use shielded Cat 5e or higher Ethernet cables.
• Use balanced XLR cables for analog input/output.
• Use Gigabit DHCP router to connect multiple access points in the same installation. Ensure it meets the following require­
ments:
◦ Gigabit ports
◦ Provides Class 0 PoE with at least 6.5 W
◦ Quality of Service (QoS) with 4 queues
◦ Diffserv (DSCP) QoS with strict priority
◦ If the router features Energy Efficient Ethernet (or Green Ethernet), ensure it is disabled from the ports dedicated for
the system
◦ Recommended: A managed switch to provide detailed information about the operation of each network link (port
speed, error counters, bandwidth used, etc.)
• Limiting cable runs to ≤100 meters between devices.
• Use same firmware version for all devices in your system.
• Ensure MXCW components and the computer are on the same network and set to the same subnet.
