⑧ Analog XLR Audio Input
Connect an external output.
⑨ Analog XLR Audio Output
Connect to an external input.
⑩ Ground Lift Switch
Lifts the ground from pin 1 of the XLR connector and the sleeve of the ¼" Audio Output to minimize ground-related noise
that can occur when connecting the XLR Audio Output or Input to a third­party device. The ON position of the switch is la­
beled lift.
⑪ Reset Button (recessed)
Press and hold the reset button for 10 seconds to reset the MXCW system to factory default settings.
⑫ Access Point Cover
Paint to match the surrounding decor and snap onto the front plate of the device.
The LCD menu and navigation buttons are inaccessible with the cover.
⑬ Ethernet Port
Connect a Cat5e (or higher) cable to a PoE source and the network.
⑭ Ethernet Status LED (Green)
◦ Off = no network link
◦ On = network link established
◦ Flashing = network link active
⑮ Ethernet Link Speed LED (Amber)
◦ Off = 10/100 Mbps
◦ On = 1 Gbps (required for digital audio routing)
⑯ Cable Routing Path
Provides a path for the Ethernet cable to enable a flush-mount.
⑰ Mounting Bracket
Allows for optional mounting to a wall, ceiling, or mic stand.

Access Point Menu

Use the access point menu to monitor and adjust system settings without a computer.
