Fronius Robacta TC 1000 Bedienungsanleitung Seite 38

+24 V
max. 20 mA
+24 V
max. 20 mA
+24 V
max. 20 mA
+24 V
+24 V
Belegung des Anschluss-Stecker Standard I/O (X1)
38
Roboter
+24 V
GND
GND
GND
+24 V
0 V
+24 V
0 V
GND
R o b a c a t T C
+24 V
GND
GND
GND
HIGH - Quick Stop
LOW - Quick Stop
HIGH - Cleaning Start
LOW - Cleaning Start
Supply Voltage
Ready
Supply Voltage
Fluid Level Control
Supply Voltage
Error
R
Spray In
S
Wire Cutter
T
GND Wire Cutter / Spray In
