VOLTCRAFT MT-52 Bedienungsanleitung Seite 41

Note:
– Use the "Hz%" button (11) to switch the display to frequency (Hz) and pulse length (%)� Each press switches
the function� Autorange is deactivated� This enables monitoring of possible ripple signal (superimposed fre-
quency)� In case of pure direct current, the frequency and % displays are "zero"� Without a measured signal,
phantom values may be displayed� They disappear when a direct current is measured�
Proceed as follows to measure AC voltages "A-AC":
2
1� Turn the DMM on and select measuring function "A"�
The table shows the different measuring functions and possible measuring ranges� Select your measuring range
and the respective measuring jacks� The display indicates "DC"�
Measuring func-
tion
μA
mA
A
2� Insert the red measuring line into the pA/mA or 10A measuring jack� Plug the black measuring line into the COM
socket�
3� Press "MODE" to switch to the AC measuring range� "AC" appears in the display� Pressing this button again, takes
you back etc�
4� Now connect the two measuring prods in series to the object to be measured (power circuit, switch etc�)� The
measured value is indicated on the display The connection principle corresponds to DC measurement�
5� After measuring, remove the measuring lines from the measured object and turn the DMM off�
Note:
– Use the "Hz%" button (11) to switch the display to frequency (Hz) and pulse length (%)� Each press switches
the function� Autorange is deactivated�
Measuring range
<4000 μA
4mA – 399 mA
400 mA – 10A
Measuring jacks
COM + mAμA
COM + mAμA
COM + 10A
