Adjustments or maintenance operations must only be per-
formed with the engine switched off and the spark plug ca-
ble disconnected.
1) Wear strong protective gloves before cleaning, main-
taining or adjusting the machine.
2) A ccurately wash the machine with water after cutting;
remove grass debris and mud accumulated in the chas-
sis to prevent it from drying and causing problems the
next time the lawnmower is used.
3) P aint on internal chassis parts may start to flake over
time due to the abrasive action of cut grass; if this hap-
pens, promptly touch-up with rust-proof paint to prevent
rusting that could corrode the metal.
4) I f accessing the lower part is necessary, only tilt the ma-
chine on the side indicated in the engine manual, follow-
ing the relevant instructions, making sure that the ma-
chine is perfectly stable before performing any interven-
tions. On side discharge models, remove the discharge
chute (if installed – see 3.1.d).
5) Do not drip petrol onto the plastic parts of the engine or
the machine to prevent damaging them and remove all
traces of spilled petrol immediately. The warranty does
not cover damage to plastic parts caused by petrol.
6) T o ensure that the machine will function prop-
erly over time, it is highly recommended to
change the engine oil regularly, following the tim-
ing indicated in the engine's Instruction Manual.
The oil can be discharged at a specialised ser-
vicing centre, or by using a syringe to suc-
tion the oil out through the filler spout, bearing in
mind you may need to repeat the operation sever-
al times in order to completely empty the tank.
Remember to top-up with oil before using the ma-
chine again.
4.1 Cutting means maintenance
All interventions on the cutting means must be done at a
specialised Centre that has the most appropriate tools and
equipment.
Only cutting means bearing the code indicated in the table
on page ix must be used on this machine.
Given product evolution, the above mentioned cutting
means may be replaced in time with others having similar
interchangeable and operating safety features.
4.2 Adjusting the converter cable (if fitted)
This adjustment is necessary when the lever (1) tends not
to remain in the « » position.
With the lever (1) in the «
juster (2) in the direction indicated by the arrow as needed
to ensure the lever remains in position.
IMPORTANT The adjustment must be made when the
engine is off.
4.3 Battery recharging (where applicable)
• Electric push-button ignition models
Read the engine instruction manual for instructions regard-
ing autonomy, recharging, reinstating and maintenance of
the battery.
The battery does not require charging in motors (3.2 b -
V). It can only be charged with an external USB charging
device (not supplied with the machine) in emergency
» position, turn the cable ad-
situations. Follow the instructions provided in the engine
manual.

4.4 Cleaning the interior

To clean the internal parts of the lawnmower:
– c onnect a water hose to its pipe fitting (1);
– l ower the cutting height as far as possible;
– a lways stand behind the lawnmower handle;
– start the engine.
5. STORAGE (5.1)
6. ATTACHMENTS
WARNING! For your safety, it is strictly prohibited
to fit any other attachment other than those included
in the following list, as they have been exclusively de-
signed for the model and type of machine you are using.
6.1 Mulching kit
(unless provided with the equipment)
It chops the grass cuttings finely and leaves them on the
lawn, instead of collecting them in the grass catcher.
7. DIAGNOSTICS
Problem description
1. The petrol-driven lawnmower doesn't work
No oil or fuel in the engine
The spark plug and filter
are not in good condition
The lawnmower's fuel tank
was not emptied at the end
of the previous season
2. The cut grass is not collected in the grass catcher
The cutting means has
received a knock
The inside of the chassis
is dirty
3. Mowing is difficult
The cutting means is not in
good condition
6
What to do if ....
Corrective Action
Check the oil and petrol
levels
Clean the spark plug and
filter which may be dirty or
replace them
The float may be blocked;
tilt the lawnmower on the
carburettor side
Have the cutting means
sharpened or replace it.
Check the fins that direct
the grass towards the
grass catcher
Clean the inside of the
chassis to ease the grass
discharge towards the
grass catcher
Have the cutting means
sharpened or replace it
