probst STS Serie Betriebsanleitung Seite 25

Models
Type knife
2x triangular knife
4) Adjustment to the desired stone height is convenient and quick via the two smooth-running hand
cranks (blade should only touch workpiece minimally)
5) Turn the cranks back by half a turn so that there is a minimum gap between the blade and the
Workpiece is created (turn both cranks up/down simultaneously to avoid jamming).
6) By pressing down the lever the stone / plate is cut through
Type knife
2x triangular knife
7) Adjustment to the desired stone height is convenient and quick via the two smooth-running hand
cranks (blade should only touch workpiece minimally)
8) Turn the cranks back by half a turn so that there is a minimum gap between the blade and the
Workpiece is created (turn both cranks up/down simultaneously to avoid jamming).
9) By pressing down the lever the stone / plate is cut through
51200075 - 51200080
STS-65
Stone size Application
Material: Concrete
Width:
650mm
• Paving stones
• Plates
Height:
10-120mm
STS-65-H
Stone size Application
Material: Concrete
Width:
650mm
• Paving stones
• Plates
Height:
10-400mm
8 / 11
Weight Order number
approx.
51200079
88 Kg
Weight Order number
approx.
51200080
98 kg
GB
