Models - probst STS Serie Betriebsanleitung

Models

3 Models
Type knife
Triangular knife
1) Adjustment to the desired stone height is convenient and quick via the two smooth-running hand
cranks (blade should only touch workpiece minimally)
2) Turn the cranks back by half a turn so that there is a minimum gap between the blade and the
Workpiece is created (turn both cranks up/down simultaneously to avoid jamming).
3) By pressing down the lever the stone / plate is cut through
Type knife
Triangular knife
1) Adjustment to the desired stone height is convenient and quick via the two smooth-running hand
cranks (blade should only touch workpiece minimally)
2) Turn the cranks back by half a turn so that there is a minimum gap between the blade and the
Workpiece is created (turn both cranks up/down simultaneously to avoid jamming).
3) By pressing down the lever the stone / plate is cut through
51200075 - 51200080
STS-33
Stone size Application
Material: Concrete
Width:
330mm
• Paving stones
• Plates
Height:
10-120mm
STS-33-F
Stone size Application
Material: Concrete
Width:
• Paving stones
330mm
• Plates
Height:
10-120mm
6 / 11
Weight Order number
approx.
51200075
41 Kg
Weight Order number
approx.
51200076
41 Kg
GB
