Data set
Parameter values can be stored in four different data sets.
If a data set is selected, the entered data is only stored in the selected data set. The other data sets
contain standard values. If no data set is selected the entered data is stored in all four data sets.
The data sets can be switched-over via control terminals (refer to section "Functions of control
terminals"). This enables the setting of different operating points of the drive or settings for different
motors.
Example 1: Carry out auto-tuning and enter motor data in data set 1.
DSet 4
. .
.
DSet 1
Setup
DSet 0
ENT
Data set
When setup is carried out the entered and measured motor data is stored in the selected data set.
Example 2: Set the motor rated voltage P370 in data set 2.
P 3702
P 370
P 3701
+
ENT
Hold
Data set
Display actual values
Parameter
R.m.s Current [A]
P211
Output Voltage [V]
P212
Active Power [kW]
P213
-1
Actual Speed [min ]
P240
Actual Frequency [Hz]
P241
P259
Current Error
Warnings
P269
Last Error
P310
Optional communication modules
RS485, Modbus or VABus:
RS232, Modbus or VABus:
Profibus-DP:
CANopen or System bus:
Communication interface X21 with RJ45 connection
For serial RS485 communication via VABus or Modbus protocol.
BONFIGLIOLI Vectron provides an interface adaptor for the USB connection of a PC. This enables
parametrization and monitoring via the PC software VPlus.
Parameter copy
Parameter values can be stored on a standard memory card and transferred from one inverter to
another inverter.
Reset to factory setting
Select P34 in menu item
values.
Key lock
Select P27 in menu item
the motorpoti function are password-protected. Ten minutes after a correct password entry the
password inquiry is displayed again.
Further information
Detailled operating instructions can be downloaded from the website of BONFIGLIOLI.
ENT
4002 U
ENT
ENT
Value of P370 in data set 2
Display
30
A
R.m.s. output current of the frequency inverter (motor current).
400 v
Output voltage of the frequency inverter.
11
Power of the motor at the current operating point.
1375
Motor speed.
50 Hz
Output frequency of the inverter (actual frequency of the motor).
F0102
The cause of error switch-off.
A0001
Warning because of a critical condition.
F0102
The last error.
CM-485
CM-232
CM-PDPV1
CM-CAN
Para
. Set P34 to 4444. This resets the parameter settings to the default
Para
and set a password. Then parameter values in menu item
CM
X21
13
GB
Para
and
