Extended settings of control terminals
Multifunction input
1-voltage 0...10V
X12.3
P452
2-current 0...20mA
X12.4
P562
3-digital NPN
4-digital PNP
GB
5-current 4...20mA
6-voltage, characteristic
7-current, characteristic
6-: programmable characteristic via P454...457
7-: programmable characteristic via P564...567
(Refer to operating instructions manual.)
Digital input/output
X11.6
P558
0-input (default)
1-output
Applications via control terminals
Voltage input and outputs
Voltage input
X13.1
GND
X13.2
Voltage output X11.1
GND
X11.2
Voltage output X13.4
Input signals
Application
Start
X11.3
X13.3
X11.4
Change direction
X11.5
of rotation
Stop
X11.3
X13.3
X11.4
X11.5
Set motor speed
X12.3
Select output
X
frequency
X
Data set
X11.6
change-over
X12.1
Protection function
Application
Motor
X12.4
temperature
Voltage input for external voltage supply
The external voltage supply enables the function of inputs, outputs and communication, even if the power supply of
the frequency inverter is switched off. Refer to section "Technical data of control terminals".
Function
T
24 VDC
GND for terminal X13.1
24 VDC
GND for terminal X11.1
10 VDC
Default function and settings
T
Enable: digital signals at both terminals.
AND
Start clockwise (cw) via rising signal edge or
Start anticlockwise (ccw) via rising signal edge.
Disable: Reset digital signal on at least one terminal.
OR
Reset Start clockwise or
Reset Start anticlockwise.
Reference speed 0 ... 10 VDC at analog input. P452=1-voltage (default). 0 V corresponds
to 3.50 Hz (default value of P418). 10 V corresponds to 50 Hz (default value of P419).
Fixed frequency change-over via
two digital inputs. Set P492=3. Set
frequency values in P480 ... 483.
Select digital inputs for P66 and
P67.
Select a frequency value via
P66 and P67.
Data set change-over via two digital inputs. The four data sets
can include different parameter values. Select a data set via
X11.6 and X12.1.
Function and settings
T
Connect a motor thermal contact.
Set P570: 1 Warning or 2 Error switch-off.
Multifunction output
X13.6
P550
1-digital
2-analog (default)
3-repetition frequency
4-pulse train
Default:
1-: Signal when output frequency exceeds 3 Hz (P510).
2-: Output of voltage proportional to speed.
3-: Frequency output. 0...24 V propotional to speed.
4-: Output of pulse train, scaled by P557.
Switchable logic of digital inputs
X11.4
P559
0-NPN
X11.5
1-PNP
X11.6
X12.1
X12.2
NPN: LOW-switching (on negative signal). Default of P562.
PNP: HIGH-switching (on positive signal). Default of P559.
Output signals
Function
T
Actual
Voltage signal proportional to frequency
X13.6
frequency
(speed). At 50 Hz (P419) output of 10 VDC.
At 0 Hz output of 0 VDC.
Operational
X13.5 Run signal. Indicates enable and start
state
command. Output frequency available.
Digital inputs
71
X11.4
72
X11.5
73
X11.6
(P558=0)
74
X12.1
75
X12.2
76
X12.3 (P452=3 NPN or 4 PNP)
77
X12.4
(P562=3 NPN or 4 PNP)
12
P554
Select
P553
signal.
P555
P557
Scaling.
X12.3
P452
3-digital input NPN
4-digital input PNP
X12.4 P562
3-digital input NPN
4-digital input PNP
X11.3 X13.3 X11.4
X11.5
1
1
0
0
1
1
1
0
1
1
0
1
1
1
1
1
P66 P67 Selection
0
0
P480
1
0
P481
1
1
P482
0
1
P483
X11.6 X12.1 Selection
0
0
1
0
1
1
0
1
Enable
Start cw
Start ccw
Stop
Default
0 Hz
10 Hz
25 Hz
50 Hz
Data set 1
Data set 2
Data set 3
Data set 4
