Commissioning
D
, Before putting the frequency inverter into operation all covers of the device must be assembled.
Warning!
!
, Switch off power supply before connecting or disconnecting terminals.
Operating via control signals
D1 Connect
- switch for enable signal
- switches for drive-starting and reversal of rotation
- potentiometer for speed control
Setup via operator panel. Refer to section "Setup
E
via operator panel".
Start drive via control signals.
D1
X12
Speed
Start
Enable
X11
1
Start drive via control signals
, After Setup switch on start signals on X11.4 (start
clockwise) or X11.5 (start anticlockwise).
The drive is accelerated to 3.50 Hz (default value
of P418).
,
In case of errors refer to section "Error messages and warnings".
,
In case of wrong direction of rotation exchange two motor phases (e.g. U and V).
Note
For the default functions of all control terminals refer to section Functions of control terminals
Assembly
A
B C Electrical connection of mains and motor
X13
X12
X11
X13
2 3 4
3
3 4 5
Operating via operator panel
Connect switch for enable signal
D2
Setup via operator panel. Refer to
E
section "Setup via operator panel".
Start drive via key of operator panel.
!
2
1.5 mm
2
max. 2.5 mm
Enable
X11
Start drive via key of operator panel
,
After Setup select function Motorpoti (menu
Local Poti F
/ , refer to section "Menus and
functions").
,
Press RUN.
The drive is accelerated to 3.50 Hz (default
value of P418).
,
Press the arrow keys to vary the speed.
"
7
D2
X13
3
X12
1 3
".
