4

Device description

5

Symbols and Illustrations

5.1 Symbols and Illustraions
Symbols
HLD
LDL
HB
HRB
HRC
HS
HV
HRA
σb (N/mm2
)
5.2 Measurement and Conversion Table
Range of measurement and conversion:
Manual
Illustrations
Leeb hardness value used with impact device D
Leeb hardness value used with impact device DL
Brinell hardness value
Rockwell B hardness value
Rockwell C hardness value
Shore hardness value
Vickers hardness value
Rockwell A hardness value
Strength value
7
