Stand-alone mode

Preset colors
In the C-- mode the device will constantly emit one of 20 preset colors.
1 Press the MENU button so many times until C-- is indicated in the display. Confirm with the ENTER
button.
2 Use the buttons UP and DOWN to adjust the desired color. Confirm with the ENTER button.
Automatic mode
In automatic mode, 4 programs are available that run at an adjustable speed.
1 Press the MENU button so many times until Auto is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired program (Au1 - Au4). Confirm with the
ENTER button.
2 Press the MENU button so many times until SPEE is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from SP 1 (slow) to
SP 9 (fast). Confirm with the ENTER button.
Sound control
Via the integrated microphone the unit can perfectly reproduce the show programs to the rhythm of the
music (sufficient bass provided).
1 Press the MENU button so many times until Soun is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to select the desired show program (So1 - So4). Confirm with
the ENTER button.
2 Press the MENU button so many times until SEnS is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to Adjust the microphone sensitivity to the volume of the music
(Se 1 = low, Se 9 = high).
3 Press the MENU button so many times until SPEE is indicated in the display. Confirm with the ENTER
button. Use the buttons UP and DOWN to adjust the running speed of the program from SP1 (slow) to
SP9 (fast). Confirm with the ENTER button.
4 If you enable the silent scene mode (on setting) in menu item SILE, the LEDs will be switched off if the
volume is too low or if there is no sufficient bass beat. If you disable this mode (off setting) the LEDs
remain on during periods without music.
Color temperature
In tEMP mode the device will constantly emit white light. The color temperature of the light beam is
adjustable.
1 Press the MENU button so many times until tEMP is indicated in the display. Confirm with the ENTER
button.
2 Use the buttons UP and DOWN to select the desired color temperature (2700K- 8000K). Confirm with
the ENTER button.
Individual color mix
In the color mode Colo each of the LEDs can be individually adjusted for intensity. The device will constantly
emit the color adjusted.
1 Press the MENU so many times until Colo is indicated in the display. Confirm with the ENTER button.
2 Now the display indicates the letter R for the color and the corresponding intensity value. Use the buttons
UP and DOWN to adjust the desired intensity.
3 Confirm with the ENTER button. Now the color green can be adjusted; then blue, white, amber and UV.
30/40 00143097, Version 1.1
