DESCRIPTION OF THE DEVICE
(1) Mounting bracket
(2) Lenses with 10 W HCL LEDs
(4) Fixation screw
(5) DMX in
(6) DMX out
(7) LED display with operating buttons
(8) Microphone
1
2
4
5
6
7
8
DMX OUT
3
(3) Infrared sensor for the remote control
9
10
11 12
POWER IN
(9) Power supply
(10) Fuse holder
(11) Power out
(12) Safety eyelet
